| Case dimension |
350mm W x 421mm D x 177mm H |
| Board |
Support 8-slot Passive Backplane |
| Drive configuration |
2 - 5.25"
1 - 3.5" FDD
1 - 3.5" HDD
|
| System cooling fans |
1x (120mm = 90CFM ea.) |
| Expansion Slots |
8x Slots |
| Connector Port (Front) |
1x PS/2 Port or 2x USB Ports (Optional) |
| Front Door |
Single Door With 1 Thumbscrew |
| Air Filter |
Inside Front Panel (Washable) |
| Thermal Management Card |
GHA-CO01 |
| Indicators |
LEDs for Power ON/OFF, HDD Activity, Fan, Temperature |
| Hold Down Bar |
Flexible Hold Down Bar Designed |
| Switch |
Power ON/OFF, System Reset, Buzzer Reset |
| Gross Weight |
15 kgs / 33.1 lbs |
| Optional Power Supply |
300W-400W (PS/2 Size Single up to 400W) or
MRW-5450V (Mini Redundant PSU up to 500W) (Rear
Installation), Max Depth 190mm |
