Supports
Intel ATX 12V ver.1.1 & 2.03 Standard. |
|
|
Compliant
With AMD K8 (Optron). |
|
|
High
Quality 2 Ball Bearing Fans, Suitable For "ALWAYS
ON" application. |
|
|
Fast
Cooling, Low Noise & Ripple. |
|
|
3
Speed Thermal Fan Control Switch. |
|
|
Fan
Grill & Gold Plated Connectors, Preventing Rust &
Bad Connection. |
|
|
I/O
Short circuit & Overload Protection Design. |
|
|
Standard
14cm blue LED fan |
|
|
5
minutes FAN delay shutdown device |
|
|
Independent
12V PCB for overclocking purpose |
|
|
Golden-coated
connector |
|
|
Active
PFC (Optional)e |
|
| Reviews
: |
|
|
|
|
| |
|
| Features |
|
- Noise
< 25dBA
- Power
Controlling IC
- Serial
ATA Support
- Green
Power Effiency > 72%
- Stead
+12V current
- FullLoad
at 0¢XC ~ 50¢XC
- Electronic
Fan Speed Switch
- PFC
Effiency > 0.996
- Remain
running fan after turning off
- Fan
Speed Adjustable
- PFC:
Passive
- Output
Protection: The power supply is designed with protection
for over-voltage, overload and short circuit as follow:
|
- Overvoltage
Protection: The over-voltage circuit is capable of preventing
the system and ist peripherals from being damaged by unexpected
surges from the inside of the outside.
- Short-Circuit
Protection: In the event of short circuit in any output
DC current, the power supply would stop automatically, preventing
high temperature or fire
- Overload
Protection: For the sake of service life of the parts, when
the total output exceeds the minimum voltage by between
110% and 150%, the power supply would stop automatically
|
| SAFETY
|
|
- UL,
CUL, TUV, SEMKO, NEMKO, DEMKO, FINKO und CB
- EMI
certification FCC, CE and BSMI
|
| Output
Specification |
|
Voltage
|
Min.
Load
|
Max.
Load
|
|
+3.3V
|
0.3A
|
35.0A
|
|
+5V
|
1.0A
|
45.0A
|
|
+12V
|
1.0A
|
30.0A
|
|
-12V
|
0A
|
0.8A
|
|
-5V
|
0A
|
0.5A
|
|
+5Vsb
|
0A
|
2.5A
|
+3.3V,
+5V=253W
+3.3V & +5V & -12V = 476W
Total Power = 500W
Max. Peak = 550W |
|
| |
|
The
description stated herein is subject to change without prior notice.
Latest :
September 28, 2005
|
|
